Products / FlexFire NBD
Category: Modular Duct Burners / HVAC & Process Air Heating
Modular duct burners for low temperature air heating with a high turndown ratio and short flame length.
per 300 mm module
max flame length
NG, LPG, Biogas
FlexFire NBD series burners are designed to operate in low temperature applications where a high turndown ratio and shorter flame length are required. FlexFire series burners are modular, with each 300mm module it generates 250KW output. FlexFire burners are designed for low temperature applications i.e- air handling units, spray dryers, industrial ovens etc.
FlexFire burners are integrated directly into the ductwork of an existing heating, ventilation, and air conditioning (HVAC) system or industrial process for low-temperature applications.
Max Rated Capacity
250KW per section (300mm module)
Gas Pressure (Natural Gas)
40 mbar
Gas Pressure (LPG)
50 mbar
Air Pressure
10 mbar
Max Flame Length
300 mm
Combustion Air Conditions
O₂ – 21%, Temp – 20°C
Process Air
Fresh air 21% O₂
Need a customised configuration for FLEXFIRE NBD SERIES?
Duct burners with an integrated combustion air blower for low temperature recirculating air heating.
Wall-mounted, packaged hot air burners with built-in controls and turndown up to 1:20.
Suction-type immersion tube burners for tank heating with over 90% thermal efficiency and ultra-low NOx.
Wall-mounted modulating burners with air-fuel stratification, turndown up to 1:30 and ultra-low emissions.
Skid-mounted, factory tested gas trains for safe and controlled delivery of gas to the burner.
Share your application, capacity and fuel details. We will recommend, size and customise the right combustion solution for you.
